Next Level Racing FLIGHT STAND PRO - Keyboard Plate Adjustment

26
support@nextlevelracing.com
PARTS:
• • 1 x Keyboard Plate
43
Align the holes on the Keyboard Plate with the through holes on the Keyboard Angle Bracket.
PARTS:
• • 2 x M8 55mm Sockethead Bolts
• • 2 x M8 Flange Nuts
• • 2 x M8 Washers
44
Bolt through and secure with 2 x M8 Bolts, Washers and Flange Nuts.
PARTS:
• • NIL
45
A) Loosen the Bolts securing the Keyboard Angle Bracket to the Mouse Plate.
B) Adjust to the desired position and tighten the bolts to lock in place.
A) B)
KEYBOARD PLATE ADJUSTMENT
