NextBase 322GW User Manual

12
4. Scan the QR Code for adhesive mount installation guide.
Watch the video to see how to best install the adhesive mount. This covers steps 5 - 10.
In Vehicle Installation (cont.)
4
5. Clean the area of the windscreen you will mount the Dash Cam.
Ensuring that the windscreen is clear of grease and dirt allows the most effective adhesion,
keeping your Dash Cam securely mounted. ideally, choose an area within the wiper zone to
allowl clear recordings in all weather conditions.
1) Use the wet wipe (green pack) to clean the windscreen in the target area.
2) Use the dry wipe (pink pack) to dry the windscreen in the target area.
1
2
5
6. Remove the adhesive pad from the Dash Cam mount.
Firmly slide the adhesive pad to the left to detach it from the mount. You will hear a click
as the pad detaches.
6
7. Remove the adhesive cover on the pad
Gently lift the cover layer to expose the adhesive pad beneath.
7

NextBase 322GW Specifications

General

Night vision	Yes
Product color	Black, Silver
Country of origin	China
Languages support	DEU, DUT, ENG, ESP, FRE, ITA, NOR
Number of cameras	1
Maximum frame rate	60 fps
Power cable length	4 m
Collision detection	No
Aperture range (F-F)	1.6 - 1.6
Main camera resolution	1920 x 1080 pixels
Main camera viewing angle	140 °
Video compression formats	MP4
Main camera sensor resolution	2.12 MP
Battery life	15 min
Battery weight	6 g
Output current	2 A
Output voltage	3.7 V
Battery capacity	320 mAh
Operating voltage	12 V
Power source type	Battery, Cigar lighter
Input operation voltage (max)	24 V
Storage temperature (T-T)	-20 - 45 °C
Display diagonal	2.5 \
Display resolution (numeric)	311 pixels
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Quantity per pack	7 pc(s)
Accessories included	Vdc Car Power Cable, Cable Tidy Tool, Click & Go Powered Mounts: Adhesive
Package type	Box
Package width	85 mm
Package height	45 mm
Package weight	410 g
Quantity per pallet	720 pc(s)
Master (outer) case width	280 mm
Master (outer) case height	370 mm
Master (outer) case length	330 mm
Master (outer) case weight	1025 g
Customs product code (TARIC)	8525890000
Master (outer) case GTIN (EAN/UPC)	5060384255675
Export Control Classification Number (ECCN)	EAR99
Number of shipping (inner) cases per master (outer) case	20 pc(s)

Weight and Dimensions

Depth	47 mm
Width	82 mm
Height	46 mm
Weight	82 g
