IN VEHICLE INSTALLATION (CONTD.)
4. The angle and position of the iN-CAR CAM can be adjusted by loosening the locking clamp and
moving as required, remembering to re-tighten the clamp.
5. Connect the car adaptor to mini-USB socket of the iN-CAR CAM and then plug the supplied car
adaptor into the 12-24Vdc outlet of your vehicle. The iN-CAR CAM will automatically power on
and start recording once power is available.
In some vehicles this will be when connections are made, for others the device will power on
once the ignition has been turned on.
Note:
- Do NOT wire the iN-CAR CAM directly to a 12V supply or damage will result.
- ONLY use the supplied car adaptor cable to supply 5Vdc to the iN-CAR CAM.
The above diagram is for illustration purposes only.
12-24V DC
12
