NextBase 522GW User Manual

29
Directions
Once in Edit Mode, you will see a white timeline bar with a green indicator and red indicator at either end.
A white ball indicates how far through playback of the current file you are.
While paused, press the ‘Trim Start’ button (top left) to move the green indicator bar to the current point
on the timeline. Once saved, anything before this point will be trimmed off.
While paused, Press the ‘Trim End’ button (top right) to move the red indicator bar to the current point
on the timeline. Once saved, anything after this point will be trimmed off.
During playback, the editing controls are greyed out, and cannot be activated, pause to use the trim tools,
remove audio, and save functions.
When moving the Start/End trim tools, make sure that the Green (start) indicator comes before theNote:
Red (end) indicator on the timeline. if the Red is placed before the Green, the save function will not work.
Edit Mode
Trim Start (green)
Press to place Start Indicator on the timeline.
Trim Start Indicator
Start point of your new file.
Trim End (Red)
Press to place End Indicator on the timeline.
Trim End Indicator
End point of your new file.
Timeline and Position Indicator (White)
Shows your current position in the recording.
When you reach the point where you want
to start your new file, press Trim Start (1a).
When you reach the point where you want
to end your new file, press Trim End (2a).
This will move the indicators (green/red).
Audio Recording
Toggle the audio ON/OFF.
Back
Pressing Back while editing will take you back
to the video preview screen. If you were in the
process of editing a video, it will not be saved.
Save
Press to save the video as a separate file that
will appear in your file library. The original file
is unaffected.
1a
1b
2a
2b
3
1a
1b 2b 2a3
4
6
4
5
5
6
Press Play to begin playback.
Playback. The white ball indicates your position.
Press Trim Start to move the Trim Start Indicator.
Continue Playback. The white ball indicates your position.
Press Trim End to move the Trim End Indicator.
Press Save to export the new file. The new file will be saved
the original file name + EDI (i.e. 180125_175618_009_FH_EDI).
If you are editing a protected file, the new file will also
be protected.
The original file is unaffected.
Playback Mode - Video Editing
The key below explains the various information displayed on the screen when your Dash Cam is in
Playback Mode (Protected/Unprotected Video).

NextBase 522GW Specifications

General

Product color	Black, Silver
G-shock sensor	No
GPS (satellite)	Yes
Country of origin	China
Number of cameras	1
Maximum frame rate	30 fps
Power cable length	4 m
Aperture range (F-F)	1.3 - 1.3
Main camera resolution	2560 x 1440 pixels
Main camera sensor size	1/3 \
Main camera viewing angle	140 °
Video compression formats	MP4
Main camera sensor resolution	5.14 MP
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Display diagonal	3 \
Battery life	15 min
Battery weight	7 g
Output current	2 A
Output voltage	3.7 V
Battery capacity	320 mAh
Operating voltage	12 V
Power source type	Battery, Cigar lighter
Input operation voltage (max)	24 V
Cables included	Mini-USB
Quantity per pack	7 pc(s)
Accessories included	Vdc Car Power Cable, Cable Tidy Tool, Click & Go Powered Mounts: Suction and Adhesive
Quantity per pallet	720 pc(s)
Master (outer) case width	230 mm
Master (outer) case height	370 mm
Master (outer) case length	330 mm
Master (outer) case weight	1000 g
Customs product code (TARIC)	8525890000
Quantity per master (outer) case	20 pc(s)
Master (outer) case GTIN (EAN/UPC)	5060384255712
Export Control Classification Number (ECCN)	EAR99
Package depth	66 mm
Package width	153 mm
Package height	125 mm
Package weight	456 g

Weight and Dimensions

Depth	45 mm
Width	94 mm
Height	53 mm
Weight	125 g
