The supplied mount has been designed to allow the easy installation into your vehicle.
Please follow instructions given below.
Car Mount Bracket
1
6
3
5
4
1. Locating hole for thumbwheel
Thumbwheel will pass through the car mount bracket here.
2. Locating hole for Anti-rotation pin
Anti-rotation pin will pass through the car mount bracket here.
3. Anti-rotation pin
This metal pin will locate through the car mount bracket and into a hole in the rear housing
of the player / monitor to stop possible rotation of the screen when vehicle is moving.
4. Car mount bracket guide
The guide is used to locate the bracket on to the car mount.
5. Locking tab recess
Locating recesses for the car mount locking tabs.
6. M6 Player bracket thumbwheel
Thumbwheel is used to secure the player bracket to the rear housing of the DVD
player / monitor, remember to fit the anti-rotation pin prior to tightening the
thumbwheel, see item 3 above.
M6 brass insert
Anti-rotation hole
Thumbwheel
Anti-rotation pin
