NB7-CAR / NB9-CAR (Player only models)
Is recommended that the DVD player is mounted behind the drivers seat, for best cable
routing.
The only connection required is 12VDC (not 24VDC) power using the supplied car adaptor.
With the vehicle running connect the car adaptor to the 12VDC outlet within the vehicle
and making sure the DVD player is turned off connect the car adaptor to the socket
marked ‘DC IN 9-12V’ which is located on the left hand side of the DVD player.
12VDC car adaptor
The DVD player can now be turned on. Please turn the DVD player off before
disconnecting the car adaptor or turning off the vehicle.
NB7T-CAR / NB9T-CAR (Player / Monitor models)
For the player / monitor models there is the standard car adaptor connection as described
above and also the audio / video / power connection between the player and monitor to be
made using the supplied cable.
DVD Player:
Insert the DC connector into the ‘DC OUT’ socket located on the left hand side of the DVD
player.
Insert the 3.5mm AV connector into the ‘AV OUT’ socket also located on the left hand side
of the DVD player.
Monitor:
Insert the DC connector into the ‘DC IN’ socket located on the right hand side of the
monitor.
Insert the 3.5mm AV connector into the ‘AV IN’ socket also located on the right hand side
of the monitor.
