NI-9361 Pinout
The NI-9361 provides connections for eight digital input channels for the embedded
counters.
DI3-
COM
DI2-
COM
DI6-
COM
DI7-
COM
DI0-
NC
DI1-
COM
DI5-
COM
COM
DI4-
COM
COM
DI3+
Vout
DI2+
Vout
Vout
DI6+
DI7+
Vout
DI0+
Vsup
DI1+
Vout
Vout
DI5+
Vout
DI4+
NC
Vout
NC
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
Table 1. Signal Descriptions
Signal Description
COM Common reference connection to isolated
ground
DI+ Digital input signal connection for singled-
ended measurements and positive digital input
signal connection for dierential measurements
© National Instruments
3
NI-9361 Getting Started
