Specifications
The following specifications are typical for the range 0 to 60 °C unless otherwise noted.
Power Requirements
Caution The protection provided by the NI USB-9162 carrier can be impaired if it
is used in a manner not described in this document.
Current consumption from USB.......................500 mA, max
Suspend mode................................................... 2.5 mA, max
Bus Interface
USB specification.............................................USB 2.0 Hi-Speed
Physical Characteristics
Weight...............................................................101 g (3.5 oz)
Dimensions .......................................................114.6 mm × 85.7 mm × 25.1 mm
(4.51 in. × 3.37 in. × 0.99 in.)
If you need to clean the module, wipe it with a dry towel.
Safety Voltages
Connect only voltages that are within these limits.
Isolation
Channel-to-channel
Continuous........................................250 VAC, Measurement Category II
Withstand..........................................1500 VAC, verified by a 5 s dielectric withstand
test
Channel-to-earth ground
Continuous........................................250 VAC, Measurement Category II
Withstand..........................................3000 VAC, verified by a 5 s dielectric withstand
test
Measurement Category II is for measurements performed on circuits directly connected to the
electrical distribution system. This category refers to local-level electrical distribution, such as
that provided by a standard wall outlet, for example, 115 V for U.S. or 230 V for Europe. Do not
connect the NI USB-9162 to signals or use for measurements within Measurement
Categories III or IV.
