Nibe VVM 225 Installer Manual

3X230V
3x230V
Compatible NIBE air/water heat pumps F2040-6 / F2040-8
F2120-8 / F2120-8 (1x230V)
NIBE SPLIT HBS 05 (HBS 05-6 / AMS 10-6) (HBS 05-12 / AMS 10-8)
Electrical data
9kWAdditional power
230V 3N~50HzRated voltage
27.5AMax operating current
32AFuse
2 – 75WOutput, GP1
IPX1BEnclosure class
Heating medium circuit
low energyEnergy class, GP1
0.3 (3 bar)MPaMax system pressure heating medium
70°CMax HM temp
Pipe connections
Ø22Heating medium
Ø22Hot water connection
Ø22Cold water connection
Ø15Hot water circulation
Ø22Heat pump connections
Other, indoor module
180lVolume, hot water heater
1.0 (10 bar)MPa (bar)Max. permitted pressure, water heater
1.0 (10 bar)MPa (bar)Cut-off pressure, hot water heater
0.3 (3 bar)MPa (bar)Max permitted pressure in indoor module
0.25 (2.5 bar)MPa (bar)Cut-off pressure, indoor module
Capacity, hot water heating according to
EN16147
130lTap volume 40°C at Economy comfort
176lTap volume 40 °C during Normal comfort
199lTap volume 40 °C during Lux comfort
Dimensions and weight
600mmWidth
615mmDepth
1,475mmHeight (without base)
1,500 – 1,525mmHeight (with base)
1,550mmRequired ceiling height
146kgWeight (excl. packaging and without water)
069 230Part number Stainless steel – VVM 225 R EM 3x230V
69Chapter 12 | Technical dataNIBE VVM 225
