Page #68 background image
Technical specifications
3X400V
3x400V
Compatible NIBE air/water heat pumps F2040-6 / F2040-8
F2120-8 / F2120-8 (1x230V)
NIBE SPLIT HBS 05 (HBS 05-6 / AMS 10-6) (HBS 05-12 / AMS 10-8)
Electrical data
9kWAdditional power
400 V 3N~50 HzRated voltage
16AMax operating current
16AFuse
2 75WOutput, GP1
IPX1BEnclosure class
Heating medium circuit
low energyEnergy class, GP1
0.3 (3 bar)MPaMax system pressure heating medium
70°CMax HM temp
Pipe connections
Ø22mmHeating medium
Ø22mmHot water connection
Ø22mmCold water connection
Ø15mmHot water circulation
Ø22mmHeat pump connections
Other, indoor module
180lVolume, hot water heater
1.0 (10 bar)MPa (bar)Max. permitted pressure, water heater
1.0 (10 bar)MPa (bar)Cut-off pressure, water heater (does not apply to part no. 069 227)
0.3 (3 bar)MPa (bar)Max permitted pressure in indoor module
0.25 (2.5 bar)MPa (bar)Cut-off pressure, indoor module
Capacity, hot water heating according to
EN16147
130lTap volume 40°C at Economy comfort
176lTap volume 40 °C during Normal comfort
199lTap volume 40 °C during Lux comfort
Dimensions and weight
600mmWidth
615mmDepth
1,475mmHeight (without base)
1,500 1,525mmHeight (with base)
1,550mmRequired ceiling height
146kgWeight (excl. packaging and without water)
069 227Part number VVM 225 E EM 3x400V
069 229Part number VVM 225 R EM 3x400V
NIBE VVM 225Chapter 12 | Technical data68
