Nibe VVM 310 Service Manual

Components
DescriptionComponent
Red coil (3 kW) resistance 55 ohmImmersion heater
(EB1)
Black coil (0.5 kW), resistance 110 ohm
White coil (3x1333 W) resistance 39.59 ohm
Brown coil (3x2667 W) resistance 19.79 ohm
B
9
5
±
2
112 ± 2
166,5 ± 2
Ø
2
8
50R ± 5
799,5 ± 7
(966)
25 ± 1
390 ± 2 353
Ø
6
3
,
5
30
R
a3.2
0
0
0
0
1
3
2
Actuator motor: 7 VA, 230/24 VAC, 50 Hz, IP 40. Running time approx 8 sec.Reversing valve
(QN10, QN35)
Max. operating pressure: 1.0 MPa
Operating temperature: 5 - 80 °C (90 °C briefly)
56 56
Ø28
30
54
106
142
Ø28
NIBE™ VVM 310Chapter 5 | Component description10
5 Component description
