Basic
Removing the covers
Front cover
1.
Remove the screws from the lower edge of the front cover.
2.
Lift the cover out at the bottom edge and up.
Side covers
The side covers can be removed to facilitate the installation.
1.
Remove the screws from the upper and lower edges.
2.
Twist the cover slightly outward.
3.
Move the hatch backwards and slightly to the side.
4.
Pull the cover to one side.
5.
Pull the hatch forwards.
Accessibility, electrical connection
The plastic cap of the electrical boxes is opened using a screwdriver.
NOTE
The cover for the input card is opened without a tool.
NIBE™ VVM 310Chapter 7 | Component replacement30
7 Component replacement
