Apollo 816 LA Linear Actuator
Installation Reference Manual
99
3: AFFIX GATE BRACKET TO ACTUATOR ARM (CONT.)
ACTUATOR
ARM
ACTUATOR
ARM
GATE BRACKET
GATE BRACKET
Fig-3C: Gate Bracket with Bolt, Washer, Nut
Fig-3D: Gate Bracket with Hitch Pin And R-Clip
1/2”x 3” BOLT
HITCH PIN
1/2” WASHER
1/2” LOCK NUT
R-CLIP
