ENGLISH – 3
– The manufacturer declines all liability for damages to
property, objects or people resulting from failure to
observe the assembly instructions. In such cases, the
warranty for material defects shall not apply.
– The weighted sound pressure level of the emission A is
lower than 70 dB(A).
– Cleaning and maintenance reserved for the user must
not be carried out by unsupervised children.
– Before intervening on the system (maintenance, clean-
ing), always disconnect the product from the mains
power supply and from any batteries.
– Inspect the system frequently, in particular the cables,
springs and supports to detect any imbalances and
signs of wear or damage. Do not use the product if it
needs to be repaired or adjusted, because defective
installation or incorrect balancing of the automation can
lead to injuries.
– The packing materials of the product must be disposed
of in compliance with local regulations.
– Keep persons away from the gate when it is manoeu-
vred using the control elements.
– When operating the gate, keep an eye on the automat-
ed mechanism and keep all bystanders at a safe dis-
tance until the movement has been completed.
– Do not operate the product if anyone is working near-
by; disconnect its power supply before permitting such
work to be done.
1.2 INSTALLATION WARNINGS
– Prior to installing the drive motor, check that all me-
chanical components are in good working order and
properly balanced, and that the automation can be ma-
noeuvred correctly.
– Make sure that the control elements are kept far from
moving parts but nonetheless directly within sight. Un-
less a selector is used, the control elements must be
installed at least 1.5 m above the ground and must not
be accessible.
– If the opening movement is controlled by a re-sensing
system, make sure that any windows larger than 200
mm are closed using the control elements.
– Prevent and avoid any form of entrapment between the
moving and xed parts during the manoeuvres.
– Permanently afx the label concerning the manual ma-
noeuvre near its actuating element.
– After installing the drive motor, make sure that the
mechanism, protective system and all manual manoeu-
vres function properly.
PRODUCT DESCRIPTION AND
INTENDED USE
2
2 PRODUCT DESCRIPTION AND INTENDED USE
M-BAR and L-BAR are electromechanical boom gates for res-
idential and industrial use, which control the opening and clos-
ing of a driveway.
These barriers are equipped with an electromechanical gear-
motor with a 24 V motor, an electric limit switch system and a
warning light incorporated in the cover (optional accessory).
These two models can be installed as counterposed barriers
in the “Master-Slave” mode, to cover the surface of a driveway
exceeding 8 metres (see paragraph “Gearmotor in SLAVE
mode“).
The control unit is congured for being connected to the var-
ious devices belonging to the Nice Opera System and to the
“Solemyo” solar power system (see paragraph “Connecting
the Solemyo solar energy system“).
The barriers work on electricity and in case of a power outage
(blackout), the boom can be unlocked manually and moved
by hand. Alternatively, it is possible to use the back-up battery
(model PS224 - optional accessory) which ensures that certain
manoeuvres can be carried out in the rst few hours of a power
outage. To prolong this period or increase the number of al-
lowed manoeuvres, it is necessary to activate the “Stand-by”
function (see “Table 5“).
The barriers must be combined with the available booms, indi-
vidually or in pairs, to reach the desired length. Various optional
accessories are available, depending on the chosen boom, as
shown in the table.
Table 1
INSTALLABLE ACCESSORIES
Cubicle Boom
Rubber
Lights
Aluminium
skirt
Mobile support
M3BAR
3 m yes yes - -
M5BAR
4 m yes yes yes (1 piece) yes
5 m yes yes yes (1 piece) yes
M7BAR
5 m yes yes yes (2 pieces) yes
3+3 m yes yes yes (2 pieces) yes
3+4 m yes yes - yes
L9BAR
3+4 m yes yes yes (3 pieces) yes
4+4 m yes yes yes (3 pieces) yes
4+5 m yes yes - -
Important notes for using the manual:
– throughout this manual, the term “boom gate” refers to the two
products “M-BAR” and “L9BAR”
– the accessories mentioned in the manual are optional.
a
Any use of the product other than the intended use
described is not allowed!
