EN - Addendum to the MBar /LBar manual

FR - Addendum au manuel MBar /LBar

Nice SpA

Oderzo TV Italia

info@niceforyou.com

MBar / LBar

Automatic barrier

M3BAR

M5BAR

M7BAR

LBAR

–– IMPORTANT SAFETY INSTRUCTIONS ––

WARNING – To reduce the risk of severe injury or death

1. Read and follow all instructions.

2. Never let children operate, or play with door controls. Keep remote control away

from children.

3. Always keep moving door in sight and away from people and objects until it is

completely closed. No one should cross the path of the moving door.

WARNING – For continued protection against fire, replace only with the same type

and rating of fuse.

WARNING – To prevent entrapment, do not start door downward unless doorway

is clear.

Installation, Operating and Safety Instructions – Instructions for installation and use of

this product are provided by the manufacturer as required by the standard.

–– IMPORTANT INSTALLATION INSTRUCTIONS ––

The installation instructions shall include the following or equivalent text.

Warning – To reduce the risk of severe injury or death:

1. READ AND FOLLOW ALL INSTALLATION INSTRUCTIONS.

2. Install only on a properly balanced garage door. An improperly balanced door has

the potential to inflict severe injury. Have a qualified service person make repairs

to cables, spring assemblies, and other hardware before installing the opener.

3. Remove all ropes and remove or make inoperative all locks connected to the ga-

rage door before installing opener.

4. Where possible, install the door opener 7 feet (2.13 m) or more above the floor.

For products having an emergency release, mount the emergency release 6 feet

(1.83 m) above the floor.

5. Do not connect the opener to source of power until instructed to do so.

6. Locate the control button: (a) within sight of door, (b) at a minimum height of 5

feet (1,52 m) so small children are not able to reach it, and (c) away from all mov-

ing parts of the door.

7. Install the Entrapment Warning Label next to the control button in a prominent lo-

cation. Install the Emergency Release Marking. Attach the marking on or next to

the emergency release.

8. After installing the opener, the door must reverse when it contacts a 1-1/2 inch

(25.4 - 12.7 mm) high object (or a 2 by 4 board laid flat) on the floor.

–– IMPORTANT USER INSTRUCTIONS ––

The user instructions shall include the following or equivalent text.

Warning – To reduce the risk of severe injury or death:

1. READ AND FOLLOW ALL INSTRUCTIONS.

2. Never let children operate or play with door controls. Keep the remote control

away from children.

3. Always keep the moving door in sight and away from people and objects until it

is completely closed. NO ONE SHOULD CROSS THE PATH OF THE MOVING

DOOR.

4. NEVER GO UNDER A STOPPED, PARTIALLY OPEN DOOR.

5. Test door opener monthly. The garage door MUST reverse on contact with a

1-1/2 inch (25.4 - 12.7 mm) high object (or a 2 by 4 board laid flat) on the floor.

After adjusting either the force or the limit of travel, retest the door opener. Failure

to adjust the opener properly increases the risk of severe injury or death.

6. For products having an emergency release, when possible, use the emergency

release only when the door is closed. Use caution when using this release with

the door open. Weak or broken springs are capable of increasing the rate of door

closure and increasing the risk of severe injury or death.

KEEP BARRIER DOORS PROPERLY BALANCED. See owner’s manual. An im-

properly balanced barrier increases the risk of severe injury or death. Have a quali-

fied service person make repairs to cables, spring assemblies, and other hardware.

8. SAVE THESE INSTRUCTIONS.

Industrial and commercial vehicular doors and door operators

• Adoorshallbeprovidedwithanadjustablecontrolmechanismandspecificin-

structions describing that adjustment of the control mechanism that allows satis-

factory operation of the door. The instructions shall also indicate the need for pe-

riodic checking of the control mechanism.

• Adooroperatorthatistobesoldwithoutthedoorshallbeprovidedwithinstruc-

tions in the instruction manual specifying the methods of wiring required to main-

tain operation in accordance with 30.1.1.

• Clearinstructionsfortheinstallationofareversing-edgeswitchshallbeprovided

with the operator.

ETL DEFINITIONS COMPLIANT TO UL325

• Vehicular Slide-Gate Operator (or system) - A vehicular gate operator (or system)

that controls a gate which slides in a horizontal direction that is intended for use

for vehicular entrance or exit to a drive, parking lot, or the like.

• Gate - A moving barrier such as a sliding, swinging, raising, lowering, rolling, or

like barrier that is a stand-alone passage barrier or is that portion of a wall or fence

system that controls entrance and/or egress by persons or vehicles and completes

the perimeter of a defined area.

• Residential Vehicular Gate Operator - Class I - A vehicular gate operator (or sys-

tem) intended for use in a home of one to four single family dwelling, or a garage

or parking area associated therewith.

• Commercial / General Access Vehicular Gate Operator - Class II - A vehicular gate

operator (or system) intended for use in a commercial location or building such as

a multi-family housing unit (five or more single family units), hotel, garages, retail

store, or other buildings servicing the general public.

• Commercial / General Access Vehicular Gate Operator - Class III - A vehicular gate

operator (or system) intended for use in a industrial location, loading dock area, or

other location not intended to service the general public.

• Commercial / General Access Vehicular Gate Operator - Class IV - A vehicular gate

operator (or system) intended for use in a guarded industrial location or buildings

such as airport security area or other restricted access locations not servicing the

general public, in which unauthorized access is prevented via supervision by se-

curity personnel.

● INTRODUCTION OF TWO NEW SECTIONS: 4.11, 4.12

4.11 - Alarm siren connection (M3BAR/V1, M5BAR/V1, M7BAR/V1 and LBAR/

V1 only)

Type V1 (120V; 50/60Hz) barriers have an integral alarm siren that sounds when the

amperometric force limiter is tripped two times during a single manoeuvre. If this hap-

pens the system stops accepting user commands; the siren continues to sound for

5 minutes (and then shuts off), but the barrier remains blocked. To release the bar-

rier press the control unit’s STOP button, or actuate the device (if present) connect-

ed to the control unit’s STOP input (fig. 41, as reported in the product instructions).

The siren is connected to control unit output OUT2 (fig. 41, as reported in the prod-

uct instructions), and this output is factory configured to operate the siren. To com-

pletely deactivate the siren, disconnect it from OUT2; the output can then be repro-

grammed for other applications.

4.12 - Cooling fan connection (M3BARHF only)

The M3BARHF barrier control unit has an integral cooling fan. The fan starts running

when the barrier is operated and remains on for 1 minute after the end of the ma-

noeuvre. The fan is connected to control unit output OUT3 (fig. 41, as reported in

the product instructions), and this output is factory configured to operate the fan. To

completely deactivate the fan, disconnect it from OUT3; the output can then be re-

programmed for other applications.

ENGLISH

IS0256A00MM_12-04-2013
