PRODUCT DISPOSAL
This product is an integral part of the automation system it controls and
must be disposed of along with it.
As in the case of installation, likewise at the end of product lifetime the disas-
sembly and scrapping operations must be performed by qualified personnel.
This product is made of various types of material, some of which can be recy-
cled while others must be scrapped. Seek information on the recycling and dis-
posal methods envisaged by the local regulations in your area for this product
category.
Caution! – Some parts of the product may contain polluting or hazardous sub-
stances which, if released to the environment, may cause serious damage to
the environment or to human health.
As indicated by the symbol alongside, disposal of this prod-
uct with domestic waste is strictly prohibited. Separate the
waste into categories for disposal, according to the methods
established by current legislation in your area, or return the
product to the retailer when purchasing a new version.
Caution! – Local legislation may impose heavy fines in the event of illegal dis-
posal of this product.
TECHNICAL CHARACTERISTICS OF THE PRODUCT
WARNINGS: • All technical specifications stated in this section refer to an ambient temperature of 20°C (± 5°C). • Nice S.p.a. reserves the right to apply modifi-
cations to products at any time when deemed necessary, maintaining the same intended use and functionality.
Product Type SBAR is an electromechanical road barrier for residential use. Controls opening and closing of
an access point with a maximum width of 4 m. Complete with electronic control unit
Maximum torque on start-up 100 Nm
Nominal torque 25 Nm
Maximum operating
cycle frequency 100 (80 with XBA4 accesory) cycles / hour
at nominal torque *
Maximum continuous operating
10 (8 with XBA4 accesory) minutes
time at nominal torque **
Opening time ≥ 4 s (>5s with XBA4 accesory)
Durability between 80,000 and 500,000 manoeuvre cycles according to the conditions stated in Table 2
Peak power supply 230 Vac (50/60Hz)
Peak power absorption on start-up 300W
Maximum power at nominal torque 200 W
Insulation class I
Emergency power supply Yes (with PS124 accessory)
Courtesy light With XBA7 LED flashing accessory
Flashing light output For 1 flashing light LUCYB, MLB or MLBT (12 V - 21 W lamp)
BLUEBUS output 1 output with maximum load of 12 Bluebus units
STOP Input
For normally closed, normally open or 8.2 kΩ; constant resistance contacts in self-learning mode
(a change from the memorised state prompts the "STOP" command)
S.S. input For normally open contacts (closure of the contact prompts the Step by Step command)
OPEN Input For normally open contacts (closure of the contact prompts the OPEN command)
CLOSE Input For normally open contacts (closure of the contact prompts the CLOSE command)
Radio AERIAL input 52 Ω for RG58 or similar type cable
Radio connector SM connector for receiver types SMXI, SMXIS or OXI, OXIT and OXIFM
Programmable functions 8 ON-OFF type functions and 8 adjustable functions (see tables 6 and 7)
Self-learning of devices connected to the BlueBus output. Self-learning of "STOP"
Functions in self-learning mode type devices (contacts NO, NC or 8,2KΩ). resistance). Learning of pole opening and closing positions and
calculation of the points of deceleration and partial opening
Operating temperature from -20° C to +50° C
Use in particularly acid,
saline or potentially No
explosive atmospheres
Protection rating IP 44
Dimensions 1146 x 330 h 179,5; pole: minimum 2 m - maximum 4 m
Weight 35 Kg
Note:
(*) At 50°C the maximum operating frequency is 40 cycles/hour
(**) At 50°C the maximum continuous operating time is 5 minutes.
