10 – English
EN
S1 6.3A T fuse
S2 6.3A T fuse
S3 6.3A T fuse
S4 6.3A T fuse
T1 transformer
Y1a network terminal block
Y1b master switch terminal block
Y1c master switch terminal block
Y2 motor screw terminal
Y3 control equipment screw terminal
J30 (Y3/6.7) loading ramp lighting connection
J9 (Y3/8-10) external trafc lights connection
J24 (Y3/11-12) internal trafc lights connection
Y4 hydraulic valve screw terminal
J12 (Y4/5.6) valve 1 connection
J13 (Y4/3.4) valve 2 connection
J14 (Y4/1.2) valve 3 connection
Y5 protection device input screw terminal
J28 (Y5/1,2) D-Pro Automatic (X4/1,2) enable
J19 (Y5/3.4) n.i.
J22 (Y5/5-7) vehicle detector
J20 (Y5/8-10) wheel chock
Y6 protection device input screw terminal
J21 (Y6/1-3) protection barrier
J23 (Y6/4-6) 8.2KOhm - loading ramp enable (door sensor)
J25 (Y6/7,8) loading ramp D-Pro Automatic (X3/4,6) enable
Y7 control elements coupling
Y8 customisation module coupling [PEEP]
Y9 sample module coupling
Y10 alarm horn coupling
Y11 service LED coupling
KEY
