196 Digitax HD M753 Control User Guide
Issue Number: 3
12.12 Menu 11: General drive set-up
Parameter
Range() Default()
Type
OL RFC-A / S OL RFC-A RFC-S
11.001 Option Synchronisation Select
Not Active (0), Slot 1 (1), Slot 2 (2), Slot 3 (3),
Slot 4 (4), Automatic (5)
Slot 3 (3)
RW Txt
US
11.002 Option synchronisation Active
Not Active (0), Slot 1 (1), Slot 2 (2), Slot 3 (3),
Slot 4 (4)
RO Txt ND NC
PT
11.017 Keypad Defined Node Address 0.000 to 255
RO Num
11.018 Status Mode Parameter 1 0.000 to 59.999 0.000
RW Num
PT US
11.019 Status Mode Parameter 2 0.000 to 59.999 0.000
RW Num
PT US
11.021 Parameter 00.030 Scaling 0.000 to 10.000 1.000 RW Num US
11.022 Parameter Displayed At Power-up 0.000 to 0.080 0.010 RW Num PT US
11.028 Drive Derivative 0 to 255 RO Num ND NC PT
11.029 Software Version 00.00.00.00 to 99.99.99.99 RO Num ND NC PT
11.030 User Security Code 0 to 2147483647 0 RW Num ND NC PT US
11.031 User Drive Mode Open-loop (1), RFC-A (2), RFC-S (3)
Open-loop
(1)
RFC-A (2) RFC-S (3) RW Txt ND NC PT
11.032 Maximum Heavy Duty Rating 0.000 to 99999.999 A
RO Num ND NC PT
11.033 Drive Rated Voltage 200 V (0), 400 V (1) RO Txt ND NC PT
11.034 Software Sub Version 0 to 99
RO Num ND NC PT
11.036 NV Media Card File Previously Loaded 0 to 999 RO Num NC PT
11.037 NV Media Card File Number 0 to 999 0 RW Num
11.038 NV Media Card File Type
None (0), Open-loop (1), RFC-A (2), RFC-S (3),
Regen (4), User Prog (5), Option App (6)
RO Txt ND NC PT
11.039 NV Media Card File Version 0 to 9999 RO Num ND NC PT
11.040 NV Media Card File Checksum --2147483648 to 2147483647 RO Num ND NC PT
11.042 Parameter Cloning None (0), Read (1), Program (2), Auto (3), Boot (4) None (0) RW Txt NC US
11.043 Load Defaults None (0), Standard (1), US (2) None (0) RW Txt NC
11.044 User Security Status
Menu 0 (0), All Menus (1), Read-only Menu 0 (2),
Read-only (3), Status Only (4), No Access (5)
Menu 0 (0) RW Txt ND PT
11.045 Select Motor 2 Parameters Motor 1 (0) or Motor 2 (1) Motor 1 (0) RW Txt US
11.046 Defaults Previously Loaded 0 to 2000
RO Num ND NC PT US
11.047 Onboard User Program: Enable Stop (0) or Run (1) Run (1) RW Txt US
11.048 Onboard User Program: Status -2147483648 to 2147483647
RO Num ND NC PT
11.049 Onboard User Program: Programming Events 0 to 65535
RO Num ND NC PT
11.050 Onboard User Program: Freewheeling Tasks Per Second 0 to 65535 RO Num ND NC PT
11.051 Onboard User Program: Clock Task Time Used 0.0 to 100.0 % RO Num ND NC PT
11.052 Serial Number LS 000000000 to 999999999 RO Num ND NC PT
11.053 Serial Number MS 0 to 999999999
RO Num ND NC PT
11.054 Drive Date Code 0 to 65535 RO Num ND NC PT
11.055 Onboard User Program: Clock Task Scheduled Interval 0 to 262140 ms RO Num ND NC PT
11.060 Maximum Rated Current 0.000 to 99999.999 A RO Num ND NC PT
11.061 Full Scale Current Kc 0.000 to 99999.999 A RO Num ND NC PT
11.062 Power Board Software Version Number 0.00 to 99.99 RO Num ND NC PT
11.063 Product Type 0 to 255 RO Num ND NC PT
11.064 Product Identifier Characters M753 RO Chr ND NC PT
11.065 Drive Rating And Configuration 00000000 to 99999999 RO Num ND NC PT
11.066 Power Stage Identifier 0 to 255 RO Num ND NC PT
11.067 Control Board Identifier 0.000 to 65.535 RO Num ND NC PT
11.068 Internal I/O Identifier 0 to 255 RO Num ND NC PT
11.069 Position Feedback Interface Identifier 0 to 255 RO Num ND NC PT
11.070 Core Parameter Database Version 0.00 to 99.99 RO Num ND NC PT
11.072 NV Media Card Create Special File 0 to 1 0 RW Num NC
11.073 NV Media Card Type None (0), SMART Card (1), SD Card (2) RO Txt ND NC PT
11.075 NV Media Card Read-only Flag Off (0) or On (1) RO Bit ND NC PT
11.076 NV Media Card Warning Suppression Flag Off (0) or On (1)
RO Bit ND NC PT
11.077 NV Media Card File Required Version 0 to 9999 0 RW Num ND NC PT
