46 Digitax HD M753 Control User Guide
Issue Number: 3
6.3 Parameter descriptions
6.3.1 Pr mm.000
Pr mm.000 is available in all menus, commonly used functions are provided as text strings in Pr mm.000 shown in Table 6-1. The functions in
Table 6-1 can also be selected by entering the appropriate numeric values (as shown in Table 6-2) in Pr mm.000. For example, enter 4001 in
Pr mm.000 to store drive parameters on an SD Card.
Table 6-1 Commonly used functions in xx.000
Value Equivalent value String Action
00
[No Action]
1001 1 [Save parameters] Save parameters under all conditions
6001 2
[Load file 1] Load the drive parameters or user program file from SD Card file 001
4001 3
[Save to file 1] Transfer the drive parameters to parameter file 001
6002 4
[Load file 2] Load the drive parameters or user program file from SD Card file 002
4002 5
[Save to file 2] Transfer the drive parameters to parameter file 002
6003 6
[Load file 3] Load the drive parameters or user program file from SD Card file 003
4003 7
[Save to file 3] Transfer the drive parameters to parameter file 003
12000 8
[Show non-default] Displays parameters that are different from defaults
12001 9
[Destinations] Displays parameters that are set
1233 10
[Reset 50Hz defs] Load parameters with standard (50 Hz) defaults
1244 11
[Reset 60Hz defs] Load parameters with US (60 Hz) defaults
1070 12
[Reset modules] Reset all option modules
11001 13
[Read enc. NP P1] Transfer electronic nameplate motor parameters to the drive from the P1 encoder
11051 14
[Read enc. NP P2] Transfer electronic nameplate motor parameters to the drive from the P2 encoder
