Nightfox PROWL - Head Mount Assembly Guide

English
10
13. Head mount assembly
There are 8 pieces for the
head mount
Slide piece A into the
bracket on top of the Prowl
(A)
Place piece B on piece A
Screw wing knob C into
pieces B and A
Slide piece D into the top of
piece A
Put piece B on piece D
A
B
C
C
B
