Nikon 1 J4 Reference Manual

160
i
Focus Lock
When Single AF is selected for Focus mode (0 155), focus lock
can be used to change the composition after focusing on the
subject in the center of the frame, allowing you to focus on a
subject that will not be in the center of the final composition. If
the camera is unable to focus using autofocus (0 156), you can
also focus on another subject at the same distance and then use
focus lock to recompose the photograph. Focus lock is most
effective when an option other than Auto-area is selected for
AF-area mode (0 159).
1
Lock focus.
Position the subject in the center of
the frame and press the shutter-
release button halfway to initiate
focus. Check that the focus area is dis-
played in green. Focus will remain
locked while the shutter-release but-
ton is pressed halfway.
2
Recompose the photograph and shoot.
Focus will remain locked between
shots.
Do not change the distance between the camera and the sub-
ject while focus lock is in effect. If the subject moves, lift your fin-
ger from the shutter-release button to end focus lock and then
focus again at the new distance.

Nikon 1 J4 Specifications

General

Sensor	CMOS
Sensor Size	13.2 x 8.8 mm
Image Sensor Format	CX
Image Processor	EXPEED 4A
Built-in Flash	Yes
External Flash	No
Storage Media	microSD, microSDHC, microSDXC
Connectivity	Wi-Fi
ISO Range	ISO 160-12800
Shutter Speed	1/16000 to 30 sec
Autofocus System	Hybrid AF
Number of Focus Points	171
Continuous Shooting Speed	Up to 20 fps with autofocus
Video Recording	Full HD 1080/60p
Screen	3.0 inch TFT LCD
Battery	EN-EL22 rechargeable Li-ion
Battery Life	Approx. 300 shots
Weight	Approx. 232 g with battery and memory card
