Nikon 1 J4 Reference Manual

171
)
Fine-Tuning White Balance
Options other than Preset manual can be fine-tuned as follows:
1
Display fine-tuning options.
Highlight an option other than Preset
manual and press 2 to display the
fine-tuning options shown at right.
2
Fine-tune white balance.
Use the multi selector to fine-tune white balance.
3
Save changes and exit.
Press J. An asterisk will appear next to the white balance
icon (0 4) in the detailed display (0 186) to show that white
balance has been altered from default values.
Increase green
Increase blue Increase amber
Increase magenta
A
White Balance Fine Tuning
The colors on the fine-tuning axes are relative, not absolute. For
example, moving the cursor to B (blue) when a “warm” setting such
as J (incandescent) is selected will make photographs slightly
“colder” but will not actually make them blue.
Coordinates
Adjustmen
t

Nikon 1 J4 Specifications

General

Sensor	CMOS
Sensor Size	13.2 x 8.8 mm
Image Sensor Format	CX
Image Processor	EXPEED 4A
Built-in Flash	Yes
External Flash	No
Storage Media	microSD, microSDHC, microSDXC
Connectivity	Wi-Fi
ISO Range	ISO 160-12800
Shutter Speed	1/16000 to 30 sec
Autofocus System	Hybrid AF
Number of Focus Points	171
Continuous Shooting Speed	Up to 20 fps with autofocus
Video Recording	Full HD 1080/60p
Screen	3.0 inch TFT LCD
Battery	EN-EL22 rechargeable Li-ion
Battery Life	Approx. 300 shots
Weight	Approx. 232 g with battery and memory card
