Nikon 1 v3 Reference Manual

103
t
4
Focus.
Rotate the multi selector until the sub-
ject is in focus. Rotate the multi selec-
tor clockwise to increase the focus
distance, counterclockwise to
decrease; the faster you rotate the
multi selector, the quicker the focus
distance changes. The focus indicator
shows the approximate focus dis-
tance. Press J when the subject is in
focus.
Press 1, 3, 4, or 2 to view areas of
the frame not currently visible in the
display; the visible portion is shown
by the navigation window.
Focus indicator
Navigation window
A
Movies
The multi selector can also be used to choose the focus distance if man-
ual focus is selected prior to movie recording. Rotate the multi selector
clockwise to increase the focus distance, counterclockwise to decrease;
the faster you rotate the multi selector, the quicker the focus distance
changes.
A
Focal Plane Position
To determine the distance between your
subject and the camera, measure from the
focal plane mark on the camera body. The
distance between the lens mounting flange
and the focal plane is approximately 17 mm
(0.7 in.).
Focal plane mark
Approx.
17 mm

Nikon 1 v3 Specifications

General

Sensor	CMOS
ISO Range	160-12800
Continuous Shooting	Yes
Display Resolution	1, 037, 000 dots
Battery Life	310 shots (CIPA)
Camera Type	Mirrorless
Image Resolution	18.4 MP
Lens Mount	Nikon 1 mount
Image Processor	EXPEED 4A
Sensor Size	13.2 x 8.8 mm
Autofocus System	Hybrid autofocus (contrast-detect/phase-detect)
Continuous Shooting Speed	20 fps
Video Recording	1080p at 60/30 fps
Display	Tilting LCD
Connectivity	Wi-Fi
Shutter Speed	30 s to 1/16000 s
Viewfinder Type	Optional electronic viewfinder
Storage Media	microSD/SDHC/SDXC
Battery	EN-EL20a rechargeable Li-ion
Weight	324 g (including battery and memory card)
Dimensions	110.9 x 65 x 33.2 mm
