Nikon 1 v3 Reference Manual

34
s
If desired, the camera can be used with an optional grip and
electronic viewfinder (0 221). Manuals are not provided; users
of these accessories will need to read following instructions in
their entirety before proceeding.
Attaching an Electronic Viewfinder
Follow the steps below to attach the viewfinder.
Attaching a Grip and Electronic Viewfinder
1
Remove the multi-accessory port cover.
Remove the cover from the camera as
shown. Be sure to replace the cover
when the port is not in use.
2
Remove the connector cover.
Remove the connector cover from the
electronic viewfinder. Be sure to
replace the cover when the viewfinder
is not in use.
Viewfinder eyepiece
Eye sensor
Diopter adjustment
control
Display-selection button
Latch release buttons (×2)
Signal contact
Connector
cover

Nikon 1 v3 Specifications

General

Sensor	CMOS
ISO Range	160-12800
Continuous Shooting	Yes
Display Resolution	1, 037, 000 dots
Battery Life	310 shots (CIPA)
Camera Type	Mirrorless
Image Resolution	18.4 MP
Lens Mount	Nikon 1 mount
Image Processor	EXPEED 4A
Sensor Size	13.2 x 8.8 mm
Autofocus System	Hybrid autofocus (contrast-detect/phase-detect)
Continuous Shooting Speed	20 fps
Video Recording	1080p at 60/30 fps
Display	Tilting LCD
Connectivity	Wi-Fi
Shutter Speed	30 s to 1/16000 s
Viewfinder Type	Optional electronic viewfinder
Storage Media	microSD/SDHC/SDXC
Battery	EN-EL20a rechargeable Li-ion
Weight	324 g (including battery and memory card)
Dimensions	110.9 x 65 x 33.2 mm
