Nikon 1 v3 Reference Manual

37
s
2
Remove the connector cap.
Remove the grip connector cap. Be
sure to replace the cap when the grip
is not in use.
3
Attach the grip.
After confirming that the camera is off, align the camera and
grip as shown and tighten the knob by rotating it in the
LOCK2 direction, keeping the grip held in place so that the
grip signal contact slides straight into the camera grip con-
nector.
A
Removing the Grip
To remove the grip, confirm that the camera is off and then loosen
the mounting screw by rotating the knob in the direction opposite
to that shown by the LOCK indicator.
D
Handling the Grip
Do not touch the signal contacts. Failure to observe this precaution
could cause product malfunction.

Nikon 1 v3 Specifications

General

Sensor	CMOS
ISO Range	160-12800
Continuous Shooting	Yes
Display Resolution	1, 037, 000 dots
Battery Life	310 shots (CIPA)
Camera Type	Mirrorless
Image Resolution	18.4 MP
Lens Mount	Nikon 1 mount
Image Processor	EXPEED 4A
Sensor Size	13.2 x 8.8 mm
Autofocus System	Hybrid autofocus (contrast-detect/phase-detect)
Continuous Shooting Speed	20 fps
Video Recording	1080p at 60/30 fps
Display	Tilting LCD
Connectivity	Wi-Fi
Shutter Speed	30 s to 1/16000 s
Viewfinder Type	Optional electronic viewfinder
Storage Media	microSD/SDHC/SDXC
Battery	EN-EL20a rechargeable Li-ion
Weight	324 g (including battery and memory card)
Dimensions	110.9 x 65 x 33.2 mm
