- D4･ E7900 -
Disassembly of rear cover
・ Take off the rear FPC insulating seal (719).
・ Remove the six screws (819).
・ The rear SW unit (1018) can be removed.
・ The determining button spring (245) can be removed.
・ The speaker (1025) can be removed.
・ Remove the determining button (241).
・ Remove the switch rubber (244).
・ The multi-selector (242) can be removed.
Speaker (1025)
Switch rubber (244)
Determining button (241)
Multi-selector (242)
Rear FPC insulating seal (719)
Screws (819)
Screws (819)
Determining button spring (245)
Rear SW unit (1018)
