- D8･ E7900 -
FPC (A)
・ Take off the FPC(A) from the double adhesive tape.
・ Remove the two screws (812).
・ Remove the screw (801).
・ Remove the FPC(B) from the connector
・ Remove the top FPC.
Top FPC
FPC (B)
Screws (812)
Screw (801)
Top FPC
