Nikon coolpix7900 - Page 15

VAA46003-R.3659.A
- D9･ E7900 -
LCD
・ Remove the three screws (815).
・ Lift up the LCD. Then, remove the FPC, the connector and the LCD.
・ Remove the lug plates (394).
・ Remove the chassis (152).
（Fig.1）
Screws (815)
Screws (815)
Lug plates (394)
LCD
FPC
LCD
Chassis (152)
Connector
