VAA46003-R.3659.A
- D23 ･ E7900 -
・ Remove the three springs #605 from the 2nd lens group unit.
・ Release the hook and then remove the shutter flexible retainer #625.
#605
#625
Hook
2. Removal of tension spring
3. Removal of shutter flexible retainer
