- D24 ･ E7900 -
・ Remove the two shutter unit mounting screws #682. ・ Remove the 2nd lens group unit from the shutter unit
#606.
・ Remove the cover ring B616 from the cam barrel #613. (It is adhered with the double adhesive tape.)
#B616
#613
Cover ring unit
4. Removal of 2nd lens group unit
#682 × 2
#606
2nd lens group
unit
