Nikon coolpix7900 - Page 35

VAA46003-R.3659.A
- A4･ E7900 -
① Hitch the three tension springs #605 onto the 2nd lens group unit.
② Apply the screw lock to the spring racks (3 places).
・ Insert the hook of the shutter flexible retainer #625 into the hole.
#605 × 3
Adhesive: Screw lock
#625
Hole
Hook
2. Setting of shutter flexible retainer
3. Setting of tension spring
