VAA46003-R.3659.A
- A28 ･ E7900 -
FPC (B)
Screw (812)
Screw (801)
Top FPC
FPC (A)
・ Set the FPC(A) onto the connector
・ Tighten the screw (801).
・ Tighten the two screws (812).
・ Fit the FPC(B) to the bosses (2 place) and adhere it.
Top FPC
