Nikon coolpix7900 - Page 58

VAA46003-R.3659.A
- A27 ･ E7900 -
Chassis (152)
FPC
Connector
LCD
LCD
Lug plate (394)
Screw (815)
Screw (815)
（Fig.1）
LCD
・ Set the chassis (152).
・ Set the lug plates (394).
・ Set the FPC and the connector. Then, set the LCD.
・ Tighten the three screws (815).
