VII. Technical specifications
66
2. When the microscope (TE2000-E, TE2000-U, TE2000-S) is used in combination
with the T-DS dia-illuminator 30W (for 6V30W lamp)
Combination
When the supply voltage is 100 to 120 V:
Microscope + T-DS dia-illuminator 30W + TE-PS30 power supply
When the supply voltage is 220 to 240 V:
Microscope + T-DS dia-illuminator 30W + TE-PSE30 power supply
Dimensions:
568(W) × 727(D) × 611(H) mm
Weight: 37 Kg
Opto-mechanical specification
Objectives: CFI60
Eyepieces: Field Number 22
Nosepiece: 6-place
Focusing:
Stroke 10 mm
Coarse 4.9 mm/rev.
Fine 0.1 mm/rev.
Fine scale 0.05 μm (TE2000-E), 1 μm (TE2000-U,S)
Input ratings of T-DS dia-illuminator
30W
DC 6 V, 30 W
Lamp ratings DC 6V30 W halogen lamp
Lamp Halogen lamp (PHILIPS 5761)
Average lamp lifetime: 100 hrs.
TE-PS30 power supply
TE-PSE30 power supply
Input ratings: TE-PS30: AC 100-120 V, 50/60 Hz, 0.6 A
TE-PSE30: AC 230 V, 50/60 Hz, 0.4 A
Voltage fluctuation: ±10%
Output ratings: DC 6 V, 30 W
Built-in fuse ratings: 250 V, F2AH
Protection class: Class 1
Others: TE-PS30: UL Recognized product
TE-PSE30: GS approved
Operating environmental conditions
Altitude: 2,000 m max.
Temperature: 0 to 40ºC
Relative humidity: 85% max. (no condensation)
Pollution degree: Degree 2
Indoor use only
Storage and transport environmental
conditions
Temperature: -20 to +60℃
Humidity: max. 90% RH (no condensation)
Installation category Category II
