ZR-6 MULTIZONE SYSTEM DESIGN GUIDE
WIRING LEGEND
Audio
CAT-5 Data
Flasher
3.5 mm
Speaker Cable
30 Pin Cable
AC
FM Antenna
AM Antenna
APPLICATION: STAND-ALONE ZR-6 MULTIZONE RECEIVER
