ZR-6 MULTIZONE SYSTEM DESIGN GUIDE
CABLE SCHEDULE
Source connections Audio Room connections (needed for each area that accesses the audio sources)
QTY CABLE SIGNAL FROM TO QTY CABLE SIGNAL FROM TO
1 Stereo RCA Audio
Satellite Receiver
Audio Output
Master ZR-6
Source 3 Input
1 Speaker Audio ZR-6 Zone Amplifier Output Speakers
1 Stereo RCA Audio
Cable Box
Audio Output
Master ZR-6
Source 4 Input
1CAT-5 Data ZR-6 Keypad Port
Keypad or
Touchscreen
1 Stereo RCA Audio CD Audio Output
Master ZR-6
Source 5 Input
1 3.5 mm 12V DC ZR-6 Global 12V Trigger AC-3 Trigger Input
1 Flasher Infrared
Master ZR-6
Flasher #3
Satellite Receiver
1 Flasher Infrared
Master ZR-6
Flasher #4
Cable Box
1 Flasher Infrared
Master ZR-6
Flasher #5
CD Player
1
iPod
(supplied)
Audio +
Data
Master ZR-6
iPod Input
iPod or SmartDock2
