64 - FORM NO. 56043088 / Advenger
™
/ BR 600S, 650S, 700S, 800S
ELECTRICAL SYSTEM
Scrub Deck Motor Type Selection:
FACTORY DEFAULT: MODE = S (SCRUBBER), SIZE: 4 IF 24”DISC / 6 IF 26” DISC / 8 IF 28” OR 32” DISC OR ANY CYLINDRICAL DECK.
The Advenger/BR 600, 650, 700 & 800 can be equipped with numerous scrub deck options. This function confi gures the control unit current settings
for each of the scrub deck types. Improper setting of the motor type may result in motor damage due to overloading. To select the proper scrub
deck motor type:
1 Turn the main power key switch to the off position.
2 Press and hold the scrub system off and scrub pressure increase switches.
3 While holding both switches turn the main power key switch to the on position.
4 Continue to hold both switches until the scrub pressure increase indicator is yellow.
5 Release both switches. The status display will now indicate “S” or “E”.
6 Pressing and releasing the scrub pressure increase switch will now select between “S” for scrubber and “E” for extractor. Make sure that “S”
is displayed.
7 Press the scrub system off switch to save this setting
8 The status display will now display “4”, “6”, or “8”. Pressing the scrub pressure increase switch will now select between the three settings. Select
“4” if the machine is equipped with a 24” disc-type scrub deck. Select “6” if the machine is equipped with a 26” disc-type scrub deck. Select
“8” if the machine is equipped with a 28” or 32”” disc-type scrub deck or any size cylindrical scrub deck.
9 Once the proper setting is displayed, press the scrub system off switch to save this setting.
10 The status display will now display “d” to indicate that the operation is done.
11 Turn the main power key switch to the off position.
CAUTION!
Improperly setting this parameter can result in serious damage to the machine. If this is set for motors not installed on the machine, the
motors may be overloaded which can cause overheating and permanent damage to the motors. It could also create a fi re hazard.
Single or Dual Vacuum Motor Selection:
FACTORY DEFAULT: 1 (SINGLE VACUUM MOTOR)
The Advenger/BR 600, 650, 700 & 800 comes with a standard single vacuum motor. A dual vacuum motor option is available. The control unit
must be programmed for the number of vacuum motors installed to provide the proper overload protection. To program the control for the number
of vacuum motors perform the following steps:
1 Turn the main power key switch to the off position.
2 Press and hold the scrub system off and vacuum switches.
3 While holding both switches turn the main power key switch to the on position.
4 Continue to hold both switches until the vacuum indicator is yellow.
5 Release both switches. The status display will now indicate “1” or “2”.
6 Pressing and releasing the vacuum switch will now select between “1” for a single vacuum motor or “2” for dual vacuum motors.
7 To save the new setting turn the main power key switch to the off position.
8 The new setting will be saved and will remain in effect until it is changed again.
Control Unit Sleep Delay Period:
FACTORY DEFAULT: 1 (10 MINUTES)
If the Advenger/BR 600, 650, 700 & 800 is left in an idle state for a period determined by the sleep delay setting the control unit will automatically
raise the scrub deck, raise the squeegee, and turn off any accessories. This is to conserve battery power. The sleep period is adjustable from 10
to 90 minutes in 10 minute increments. It can also be turned off. To change the sleep delay period perform the following steps:
1 Turn the main power key switch to the off position.
2 Press and hold the scrub system off and the wand switch.
3 While holding both switches turn the main power key switch to the on position.
4 Continue to hold both switches until the wand indicator is fl ashing.
5 Release both switches. The status display will now indicate a number from 0 to 9 depending on the current sleep delay period.
6 Pressing and releasing the wand switch will now select the delay period. The level will increment from 0 to 9; 0 = off (sleep disabled), 1 = 10
minutes, 2 = 20 minutes, ... up to 9 = 90 minutes.
7 To save the new setting turn the main power key switch to the off position.
8 The new setting will be saved and will remain in effect until it is changed again.
SPECIAL PROGRAM OPTIONS (CONTINUED)
