FORM NO. 56043093 / Captor
™
4300, 4800, 5400 / CR 1100, 1200, 1400 -
99
99
9
Copyright 2003 Nilfisk-Advance.
Page 2 of 2
10/14/2003
Ref
VISUAL INSPECTION ITEMS (continued)
Comments
OK
Defect Codes
(circle)
Does
Not
Work
36 Broom Housing & Door Skirts
D M W
37 Battery Clean & Water C W
38 Engine Air Cleaner Element (inner & outer) Check SVR Indicator C W
39 Circuit Breaker/Relay panel (inspect electrical connections) C D
40 Hydrostatic Dump Valve (Tow Valve) B
41 Propulsion drive & Accessory Pumps L
42 Hydraulic System Hoses & fittings L
43 Propulsion Pump Hydro Back Cable & Clevis Connections
B M W
44 Propulsion Pump Hydraulic Filters Change with reservoir
filter
L
45 Engine, Oil Level, Hoses & Belts Add or Change L W
46 Engine Coolant Level Fill at reservoir L Add Coolant
47 Radiator & Oil Cooler Core Blockage L Needs Cleaning
48 Hydraulic Oil Reservoir Level (10W-30 engine oil only) Middle of sight glass L Add Oil
49 Steer Spindle & Drive Wheel motor (remove recovery tank) Grease pinion & rack D L
50 Rear Tire (check lug nut torque 100 FT LB, 135Nm)
L M W
51 Gasoline/Diesel Fuel Tank , Filter & Lines C L
52 LP Tank, Hoses & Fittings L
53 LP Fuel Filter SVR Life 1500 Hrs L Replace
54 LP Fuel Regulator, Lock Off Valve & Hoses L
55 Diesel Glow Plug Indicator Light Hard Starting Replace
56 Diesel Fuel Filter Yearly L Replace
57 Scrub Brushes, check for wear and rotate
D M W
58 Scrub Deck Skirts
D M W
59 Solution Solenoid Valve
D L W
60 Solution Flow Control Valve and Linkage A B D W
61 Solution Tank, Delivery Hoses & Filter Clean filter screen C L
62 Vacuum Motor Gasket & Metal Elbow Gasket
C D L
63 Vacuum Stand Pipe Screen Clean Screen
C D M
64 Recovery Tank Cover Gasket
L M W
65 Recovery Tank Drain Hose & Cap
C D L
66 Squeegee Pick-Up Hose & Metal Elbow Back flush
C D L
67 Squeegee Tool & Blades Clean & Rotate
A D W
68 Squeegee Casters (lubricate)
A D W
69 Squeegee Hydraulic Lift Cylinder
B D L
70 Rear Drive Wheel Motor L
71 Front & Rear Tires tread wear W
NOTE: For additional service information see service manual form number 56043093 and
operators manual form number 56041547.
Defect Codes A needs adjustment C dirty or contaminated M missing
B binding D damaged, bent or torn W worn out
L leaks
WORK COMPLETED BY: ACKNOWLEDGED BY:
Service Technician Signature Date Customer Signature Date
