8 - FORM NO. 56043093 / Captor
™
4300, 4800, 5400 / CR 1100, 1200, 1400
Copyright 2003 Nilfisk-Advance. Page 1 of 2 10/14/2003
Advance Captor 4300/4800/5400 G/P/D
Nilfisk CR 1100/1200/1400 G/P/D
PM Checklist
Defect Codes
Customer
A needs adjustment
B binding
Address
C dirty or contaminated
D damaged, bent or torn
City
St Zip L leaks
M missing
Model
Serial Hours W worn out
Ref
OPERATIONAL INSPECTION ITEMS
OK
Defect Codes
(circle)
Does
Not
Work
1 Check Neutral Safety Switch Operation (To test depress drive pedal and start the
engine, it should not start.)
A B C
2 Engine Starting with pedal in neutral (if it will not start check neutral safety switch) A
3 Engine Idle 1200rpms A rough
4 Engine High Speed (high switch setting) 2400 RPM A low power
5 Drive Pedal Linkage (check for FWD/REV drive and any neutral creep) A B
6 Drive System Performance Noisy sluggish
7 Brakes (check both service & parking)
A B W
8 Steering excessive play
9 Hopper Up/Down (also check operation of the safety hopper support) A B
10 Hopper Dump Door Open/Close A B
11 Main Broom Raise /Lower A B
12 Side Broom Raise /Lower
A B C
13 Main Broom On/Off (will drift)
A B C
14 Side Broom On/Off <----->
15 Scrub System (Raise/Lower and auto scrubbing functions) <----->
16 Scrub Brush (pressure settings 1,2 &3) A B
17 Squeegee System (Raise/Lower and Auto Lift in Reverse) A B
18 Vacuum Performance (Sealed water lift 22" and 1- inch open hole adapter 20 inches)
C L W
19 Solution Control (On/Off and Flow Volume Min/Max) C L
20 Perform the machine self-diagnostic test. (see manual PN 56043093) <----->
21 Headlights, Gauges and (optional) accessories Rotating Beacon, Backup Alarm <----->
22 Dust Control Filter Shaker & Impeller <----->
23 Tilt Steering Mechanism and Seat Adjustment lever A B
Ref
VISUAL INSPECTION ITEMS
Comments
OK
Defect Codes
(circle)
Does
Not
Work
24 Side Broom Height (min bristle wear 3 inches) A B D W
25 Side Broom Motor B L
26 Hopper Cover Gasket D W
27 Hopper Dust Filter & Gasket D W
28 Impeller Motor (remove cover to access motor, fan & valve)
C L W
29 Hopper Dump Door Cylinder
A B L
30 Hopper Skirting & Seals (raise hopper to inspect)
D M W
31 Hopper Dump Door & Seal A B D W
32 Brake Cable, Brake Shoes & Drum Wear
A B W
33 Hopper Lift Cylinder & Magnetic Switch
A B L
34 Main Broom Pattern Adjustment (min bristle wear 2-1/2"
6.4cm length) & Magnetic on/off broom switch
2" (5 cm) wide pattern A B D W
35 Main Broom Motor (open left side access door to inspect) B L
To Next Page
