6 - FORM NO. 56043093 / Captor
™
4300, 4800, 5400 / CR 1100, 1200, 1400
MAINTENANCE SCHEDULEMAINTENANCE SCHEDULE
MAINTENANCE SCHEDULEMAINTENANCE SCHEDULE
MAINTENANCE SCHEDULE
Maintenance intervals given are for average operating conditions. Machines used in severe operational environments may require
service more often.
MAINTENANCE ITEMMAINTENANCE ITEM
MAINTENANCE ITEMMAINTENANCE ITEM
MAINTENANCE ITEM
PERFORM DAILYPERFORM DAILY
PERFORM DAILYPERFORM DAILY
PERFORM DAILY
Perform the “After Use” maintenance steps X
Check parking brake X
Check engine oil X
*Clean main and side brooms X
Check filter indicator and lights (hyd & air) X
Check engine coolant level X
Check hydraulic oil level X
MAINTENANCE ITEMMAINTENANCE ITEM
MAINTENANCE ITEMMAINTENANCE ITEM
MAINTENANCE ITEM
15 hrs.15 hrs.
15 hrs.15 hrs.
15 hrs.
30 hrs.30 hrs.
30 hrs.30 hrs.
30 hrs.
150 hrs.150 hrs.
150 hrs.150 hrs.
150 hrs.
300 hrs.300 hrs.
300 hrs.300 hrs.
300 hrs.
500 hrs.500 hrs.
500 hrs.500 hrs.
500 hrs.
1000 hrs.1000 hrs.
1000 hrs.1000 hrs.
1000 hrs.
*Rotate main broom X
Clean solution filter X
*Inspect/adjust brooms X
*Clean hopper filter X X X
*Inspect broom housing skirts X
*Inspect hopper seals X
Clean radiator and oil cooler X
Perform engine maintenance X
*Inspect and grease steering rack X
Change the hydraulic “charge” oil filter X
Change reservoir hydraulic oil and filter X
Flush the radiator X
Engine fuel filter(s) gas or propane X
*See the Mechanical Repair Service Manual and Operator Manual for detailed maintenance information of systems listed.
• Sweeping
• Hopper
• Steering
• Dust control
• Squeegee
WARNING!WARNING!
WARNING!WARNING!
WARNING!
Turn the key switch off, set the parking brake and disconnect the battery before servicing the machine.
AFTER USEAFTER USE
AFTER USEAFTER USE
AFTER USE
11
11
1 Raise the squeegee, the scrub brushes, and the brooms.
22
22
2 Shake the dust control filter and empty the hopper.
33
33
3 Drain and flush the recovery tank.
44
44
4 Flush the vacuum hose and squeegee by opening the recovery tank lid and running water down the pickup tube on the right side
of the tank.
SERVICE NOTE:SERVICE NOTE:
SERVICE NOTE:SERVICE NOTE:
SERVICE NOTE: Tip the recovery tank out and check the squeegee hose elbow below the tank to make sure it has
flushed out completely.
55
55
5 Remove and clean the squeegee tool (adjust as needed*).
66
66
6 Remove and clean the scrub brushes. Rotate the scrub brushes.
77
77
7 Wipe the machine with a damp cloth.
88
88
8 Perform all required maintenance before storage.
99
99
9 Move the machine to a clean, dry storage area.
1010
1010
10 Store the machine with the brooms, the squeegee and the scrub brushes in the UP position, and the tank covers open so that
the tanks can air out.
LUBRICALUBRICA
LUBRICALUBRICA
LUBRICA
TING THE MACHINETING THE MACHINE
TING THE MACHINETING THE MACHINE
TING THE MACHINE
Steering RackSteering Rack
Steering RackSteering Rack
Steering Rack
Once every 150 hours pump a small amount of grease onto the steering rack and pinion components.
Also every 150 hours apply light machine oil to maintain free movement of all general pivot points. Example the seat, and broom door
hinges etc. Broom, squeegee and hopper pivots use composite bearings lubrication is not required.
MAINTENANCEMAINTENANCE
MAINTENANCEMAINTENANCE
MAINTENANCE
