C313
4
07/2018
CTS22 / CTS22 L-M-H / CTS40 L-M-H / CTT40 L-M-H / CTT40 IECEx
GB
Vacuum cleaner description
This vacuum cleaner creates a strong air ow which is drawn
in through the inlet (5, Fig. 1) and blows out through the
exhaust (6, Fig. 1). After the hose and tools have been tted,
make sure that the motor turns correctly.
The vacuum cleaner is supplied with a check valve (Clapet,
CTS series) which prevents air and materials from coming out
of the dust container, even if the electric motor rotates in the
opposite direction than the one expected.
Before turning on the vacuum cleaner, t the vacuum hose
into the inlet and then t the required tool on to the end part.
Refer to the manufacturer’s accessory catalogue or Service
Centre.
The diameters of the authorised hoses are given in the
technical specications table.
The vacuum cleaner is equipped with a primary lter which
enables it to be used for the majority of applications.
Besides the main lter which retains the more common types
of dust, the vacuum cleaner can be tted with an upstream
absolute lter and a downstream absolute lter, with a higher
ltering capacity for ne dust and substances harmful for the
health.
Optional kits
Various optional kits are available for converting the vacuum
cleaner:
■ removable separator
■ lifting bracket
■ upstream absolute lter
■ downstream absolute lter (not for IECEx version)
■ grill and depressor with bag (not for IECEx version)
■ safe bag system
■ basket for accessories
■ paper bag (not for IECEx version)
On request, the vacuum cleaner can be supplied with optional
kits already installed. However, they can also be installed at a
later date.
Please contact the manufacturer’s sales network for further
details.
Instructions for installing the optional are included in the
conversion kit.
WARNING!
Use only supplied and authorized genuine spare parts.
Machine parts and labels
Figure 1
1. Identication plate which includes:
• Manufacturer’s name and address
• Designation and model, including class (L, M or H)
• EC Mark
• Technical specications
• Serial number
• Year of manufacture
• Weight (kg)
2. Warning label
(For L, M, H version)
3. Panel power plate
Indicates that the panel is powered by the voltage
indicated on the data plate.
4. Attention plate
Draws the operator’s attention to the fact that the lter
must only be shaken when the vacuum cleaner is o.
Failing this, the shaking would have no eect while the
lter itself could be damaged.
5. Inlet
6. Outlet
7. Check valve (Clapet) (CTS series; L, M, H versions)
8. Vacuum unit (A CTS series, B CTT series)
9. On/o switch
10. Vacuum hose
11. Closing plug (M, H versions)
12. Band latch
13. Container release handle
14. Phase sequence indicator (CTT series)
Figure 2
1. L class label
2. M class label
3. H class label
The class L and M labels contain pictograms with the following
meanings:
WARNING!
This vacuum cleaner contains dust
hazardous for the health.
Only authorised personnel wearing
suitable personal protective equipment should empty
and service the vacuum cleaner, including removing
the means used to vacuum the dust. Do not use
without the complete lter system in place.
The class H label contains the above text.
