Nilfisk-Advance CTS22 Series - Technical Specifications

CTS22 / CTS22 L-M-H / CTS40 L-M-H / CTT40 L-M-H / CTT40 IECEx
07/2018
7
C313
GB
Technical specications
Parameter Units CTS22
CTS22
L, M, H
CTS40
L, M, H
Frequency HZ 50
Voltage V 400 400
Power rating kW 2.2 4
Power rating (EN 60335-2-69) (50 Hz) kW 2.1 2.7
Noise level (L
pA
) (***) dB(A) 62 65
Protection IP 55 55
Insulation Class F F
Container capacity L 50 50
Inlet (diameter) mm 70 70
Vibration, a
h
(**) m/s
2
≤2.5 ≤2.5
Max vacuum hPa - mbar 300 - 300 /
Max vacuum with limiting valve hPa - mbar / 210 - 210 230 - 230
Maximum air ow rate(without hose and reductions) m
3
/h - L/min’ 318 - 5.300 420 - 7.000
Maximum air ow rate (with hose, length: 3 m, diameter: 50 mm) m
3
/h - L/min’ 235 - 3.915 280 - 4.670
Hoses allowed for “L” and “standard” classes (diameter) mm 70
(*)
/50 70
(*)
/50
Hoses allowed for “M” and “H” classes (diameter) mm / 50 50
Main lter surface for “standard”, “L” and “M” classes m
2
1.95 1.95
Upstream absolute “H” lter surface - HEPA 14 according to MPPS method (EN 1882) m
2
2.4 2.4
Downstream “ULPA 15” absolute lter surface m
2
1.1 1.1
“Version standard, L and M” weight kg 100 114
“Version H” weight kg 105 119
(*) Only for non-ATEX-IECEx use
(**) Total value of vibration output to the operator arm and hand
(***) Measurement uncertainty KpA <1.5 dB(A). Noise emission values obtained according to EN-60335-2-69
Dimensions
Figure 4
Model CTS22 L-M-H CTS40 L-M-H
A (mm) 1.050 1.050
B (mm) 600 600
C (mm) 1.250 1.250
■ Storage conditions:
T : -10°C ÷ +40°C
Humidity: 85%
■ Operating conditions:
Maximum altitude: 800 m
(Up to 2.000 m with reduced performances)
T : -10°C ÷ +40°C
Humidity: 85%
