9.4 Technical Data
MH 4M Descr.
4M-
140/560 X
4M-
165/820 X
4M-
180/860 L
4M-
180/860 X
4M-
170/890
4M-
170/890
4M-190/960
4M-190/960 X
4M-190/960
4M-190/960 X
4M-200/1010
4M-200/1010 X
4M-
200/1010
Voltage 200 V / 3~ / 50Hz
JP
Voltage 200 V / 3~ / 60Hz JP
Voltage 220 V / 1~ / 60Hz
Voltage 230 V / 1~ / 50Hz EU
Voltage 230 V / 1~ / 60Hz
Voltage 240 V / 1~ / 50Hz
Voltage 400 V / 3~ / 50Hz EU EU EU EU / AU EU
Voltage 400/230 V / 3~ / 50Hz NO
Voltage 220/440 V / 3~ / 60Hz EXPT
Fuse
A 16 16 16 16 20 20 16 25 / 16 16 15 / 25
Power rating
kW 3.1 4.7 5.2 5.2 4.8 4.7 6 / 6.1 6.2 / 6 6.5 / 6.7 6.4 / 6.3
Power consumption
A 15.1 9.2 9.7 9.7 18.9 16.8 13 / 13.1 22.5 / 12.4 12.5 / 12.7
12.4 /
22.5
Type of protection
IP X5 IP X5 IP X5 IP X5 IP X5 IP X5 IP X5 IP X5 IP X5 IP X5
Working pressure
bar
(Mpa)
135
(13.5)
165 (16.5) 180 (18) 180 (18)
170
(17)
170
(17)
190
(19)
190
(19)
200
(20)
200
(20)
Permissible pressure P
max
bar
(Mpa)
210 250 250 250 250 250 250 250 250 250
Volume fl ow (max)
l/h 565 820 860 860 890 890 960 960 1010 1010
Volume fl ow Q
IEC
l/h 525 760 800 800 830 830 900 900 960 960
High pressure nozzle
0340 0450 0450 0450 0500 0500 0500 0500 0500 0550
Temperature t
max
, hotwater °C 90 90 90 90 90 90 90 90 90 90
Temperature t
max
, steam °C 150 150 150 150 150 150 150 150 150 150
Max. water inlet temperature
°C 40 40 40 40 40 40 40 40 40 40
Max. water inlet pressure
bar
(Mpa)
10(1) 10(1) 10(1) 10(1) 10(1) 10(1) 10(1) 10(1) 10(1) 10(1)
Dimensions l x w x h
mm
1053 x
687 x
760
1053 x 687
x 760
1053 x
687 x
760
1053 x
687 x
760
1053 x
687 x
760
1053 x
687 x
760
1053 x 687
x 760
1053 x 687
x 760
1053 x 687
x 760
1053 x
687 x
760
Weight kg 136 136 125 136 136 136 136 / 141 136 / 141 136 / 141 136 / 141
Calculated sound pressure at
a distance of 1 m EN 60704-1
L
pA
+/- K
pA
*
dB(A)
80
+/- 1,5
80
+/- 1,5
80
+/- 1,5
80
+/- 1,5
75
+/- 1,5
75
+/- 1,5
76
+/- 1,5
76
+/- 1,5
77
+/- 1,5
77
+/- 1,5
Sound power level L
wA MAX
including K
wA
= 1,5dB *
dB(A) 94 94 94 94 91 91 91 91 92 92
Vibration ISO 5349
m/s²
≤ 2,5 ≤ 2,5 ≤ 2,5 ≤ 2,5 ≤ 2,5 ≤ 2,5 ≤ 2,5 ≤ 2,5 ≤ 2,5 ≤ 2,5
Recoil forces N 18.2 30.1 33.3 33.3 36 37 38 38 42 42
Heating capacity
kW 48 61 51 61 66 66 66 66 66 66
Fuel tank
l15 15 15 151515 15 15 15 15
Detergent tank A / B
l10 10 10 101010 10 10 10 10
Oil quantity l1 1 1 1 11 1 1 1 1
Oil type
BP Energol
GR-XP 220
* Noise emission acc. to EN 60335-2-79 ZAA.2.7
