SC3500 QUICK START GUIDE ENGLISH
6
TECHNICAL PARAMETERS
WARNING!
On some points of the machine there are some adhesive plates indicating:
—DANGER!
—WARNING!
—CAUTION!
—CONSULTATION
While r
eading this Manual, the operator must pay particular attention to the symbols shown on the plates. Do
not cover these plates for any reason and immediately replace them if damaged.
Rated power (W) 2658
Airflow (l/sec.) 19.46
Vacuum (kPa) 15.5
Voltage (V) 24
Sound pressure level at 1.5 m (dB(A) ISO 3744) 69
Max. speed (km/h) 6
Length x width x height (mm 1620x760x1250
Brush speed (RPM) 180
Solution/recovery tank (l) 110/110
Brush pressure (kg) 35/50
Scrubbing width (mm) 710
Min. turn-around aisle width (cm) 225
Max. climbing rate (%) 10
Productivity theoretical/actual (m²/h) 4260/2980
Insulation class III
Brush/pad diameter (mm) 355/355
IP protection class IP24
Net weight (kg) 230
Water flow (l/m) 1.2/3.5
Vacuum motor power (W) 500
Max. running time 4
Brush motor (W) 500
Battery compartment size (L x W x H) (mm) 590x390x350
Gross weight (gvw) (kg) 545
Brush quantity and type 2 Disc
Technical Specification Technical Specification Value
