SC3500 QUICK START GUIDE ENGLISH
4
MACHINE DESCRIPTION
MACHINE STRUCTURE (as shown in Figure 1)
1. Steering wheel
2. Seat cushion
3. Recovery tank cover
4. Utility caddy (*)
5. USB charging port
6. Front lights
7. Front wheel & Drive motor
8. Brush
9. Brush assembly
10. Brush deck
11. Rear wheel
12. Squeegee assembly
13. Solution outlet cover
14. Mop frame (*)
15. Recovery tank
16. Warning light (*)
17. Recovery tank drain hose
18. Tank
19. Squeegee adjustment knob
20. Vacuum hose
21. Squeegee knob
22. Squeegee hasp
23. Control panel
24. Key switch
25. Emergency switch
26. Accelerate pedal
27. Solution level indicator
28. Batteries
29. Battery tray for wet battery (*)
29
12
10
9
6
5
32
1
11
8
7
4
15
14
13
16
28
27
24
23
22
21
20
19
18
17
26
25
Figure 1
