ENGLISH USER MANUAL
8 SC351 - 9099864000
TECHNICAL DATA
Description SC351 SC351 full PKG
Solution tank capacity 11 litres
Recovery tank capacity 11 litres
Min/max machine length at the handlebar 810 mm/1,270 mm
Machine width 470 mm
Min/max machine height with adjustable handlebar 550/1,000 mm
Minimum width for turnaround 850 mm
Cleaning width 370 mm
Diameter of wheels on xed axle 214 mm
Wheel pressure on the oor 0.5 N/mm
2
Brush/pad diameter 370 mm
Brush/pad pressure on the oor 18 Kg
Brush/pad pressure with full tank 27 Kg
Min/max solution ow
One drop, “ECO”: 0.25 litres/min
Two drops: 0.5 litres/min
Sound pressure level at workstation (ISO 11201, ISO 4871, EN 60335-2-72) (LpA)
65 dB(A) ± 3 dB(A)
Machine sound pressure level (ISO 3744, ISO 4871, EN 60335-2-72) (LwA)
84 dB(A)
Vibration level at the operator’s arms (ISO 5349-1, EN 60335-2-72)
< 2.5 m/s
2
Maximum gradient when working 2 %
IP protection class
X4
Protection class (electric)
III
Vacuum system motor power 200 W
Vacuuming 710 mmH
2
O
Brush/pad-holder motor power 260 W
Brush/pad-holder motor speed 120 rpm
Total absorbed power 0.5 kW
Battery compartment size 350 x 175 x 240 mm
Battery voltage 12 V
Standard battery -
12V 55AhC20 AGM
spiracell
Battery charger 100-240 VAC
Work autonomy (standard battery) 1 hour
Weight without battery and with empty tanks
43 kg 43 kg
Gross vehicle weight (GVW) 80 kg
Shipping weight
48 kg 70 kg
Machine material composition and recyclability
Type Recyclable
percentage
SC351 and SC351 full PKG weight
percentage
Aluminium 100% 18%
Electric motors - various 29% 9%
Ferrous materials 100% 20%
Wiring harness 80% 9%
Liquids 100% 0%
Plastic - non-recyclable material 0% 11%
Plastic - recyclable material 100% 18%
Polyethylene 92% 9%
Rubber 20% 7%
