USER MANUAL ENGLISH
9099864000 - SC351 11
BEFORE MACHINE START-UP
Brush/pad-holder installation/removal
NOTE
Install either the brush (A, Fig. 1) or the pad-holder (B and C) according to the type of oor to be cleaned.
1. Slightly lift the machine brush deck and place the brush under the deck.
2. Turn the function selection knob (31) to program (32).
3. Press the enabling push-button (38) together with the brush levers (39) to engage the brush/pad-holder.
Remove the brush/pad-holder deck by performing the following procedure:
4. Check that the function selection knob (31) is turned to “0”.
5. Slightly lift the machine brush deck, then manually release the brush/pad-holder from the hub, by turning it abruptly in its
normal rotation direction (D).
Front
A
B
C
D
D
Figure 1
P100407
Available brushes and their relevant application guides (suggestions only)
Models MIDLITE GRIT 180 MIDGRIT 240 PROLITE UNION MIX
General cleaning
Concrete
Terrazzo oor
Ceramic tiles/quarrystones
Marble
Vinyl tiles
Rubber tiles
Polishing
Rubber tiles
Marble
Vinyl tiles
Solution tank lling
6. Open the plug (21) and ll the tank (22) with a solution suitable for the work to be performed. Do not ll the solution tank
completely, leave few centimetres from the edge. Always follow the dilution instructions on the label of the chemical product
used to prepare the solution. The solution temperature must not exceed 40°C.
CAUTION!
Use only low-foam and non-ammable detergents, intended for automatic scrubber applications.
WARNING!
When using oor cleaning detergents, follow the instructions on the labels of the detergent bottles.
To handle oor cleaning detergents, wear suitable gloves and protections.
Adjustments
7. Press the lever (40) and adjust the handlebar (2) to reach a comfortable position.
