Nixie Tube Clock ‘Nixie QTC’
Issue 11a (11 December 2014)
www.pvelectronics.co.uk
- 12 -
4. ASSEMBLY OF THE PCB
DUE TO PRODUCT DEVELOPMENT AND IMPROVEMENTS,
YOUR PCB MAY NOT LOOK EXACTLY LIKE THE ONE
PICTURED.
4.1 Low Voltage Power components:
J1, FUSE
D1-D3 (1N5819)
D4 (62V Zener Diode)
IC1 (LM2576)
L2 (100uH Inductor)
C1, C2 (220uF)
Start by installing D1-D4. Align the band on the components with
the band marked on the PCB.
