Nixie Tube Clock ‘Nixie QTC’
Issue 11a (11 December 2014)
www.pvelectronics.co.uk
- 54 -
11. CONNECTIVITY DIAGRAM FOR TROUBLESHOOTING
Please refer to the diagram on the next page. If you have problems with
missing digits from the display or no digits displaying at all (even though
High voltage is present and the clock makes bleeps when pressing the
'SET' Button) then you should check all connections to the HV5812 IC
using the chart below.
Set your meter to continuity setting. This is the setting where it bleeps
when you touch the two probes together.
11.1 Data connections from IC2 to IC3
IC3 (HV5812)
Pin Number
IC2 (PIC 16F1936)
Pin Number
Function
27 3 Data
15 4 Clock
16 5 Strobe
11.2 Cathode connections from IC3 to tube pin headers
IC3 (HV5812)
Pin Number
NX1, NX2, NX3
Cathode
IC3 (HV5812)
Pin Number
NX4, NX5, NX6
Cathode
17 K5 3 KK9
18 K4 4 KK8
19 K6 5 KK7
20 K7 6 KK6
21 K3 7 KK4
22 K2 8 KK5
23 K1 9 KK0
24 K0 10 KK1
25 K9 11 KK2
26 K8 12 KK3
