Nokia 3100 Service Manual

nokia
CONNECTING PEOPLE
PAGE 4 (22) Approved 1.0
Nokia Mobile Phones Customer Care EMEA
DJk
Technical Services, Repair Concepts Confidential 22.08.2003
2. GENERAL REPAIR INFORMATION
IN THIS SECTION THE TECHNICIAN WILL GET SOME GENERAL HINTS HOW TO CARRY OUT REPAIRS:
o To familiarize oneself with Nokia 3100 read the user guide on www.nokia.com
-->Support--> Phones,
by selecting the Phone Model.
o Before starting the repair you must take care of ESD precautions like being in your ESD Protected Area
and connecting your wristband.
o Use gloves to avoid corrosion and fingerprints.
o Protect windows and displays with a film to avoid dust and scratches.
o When cleaning the pads you have to use a soft cloth/ESD brush and Isopropanol. It is not allowed to use
a glass fiber pencil because it scratches the surface and will lead later on to corrosion.
o Mechanical parts (except shielding lids), which didn’t repair the failure, can be reused, if they are not
soldered.
o When removing the shielding lids make sure to replace them with new ones, otherwise the high-
frequency leakage can have an influence on the device.
o Use always original Nokia spare parts.
o Check the soldering joints of the parts which are concerned regarding the indicated error
(e.g. soldered connectors or switches) and resolder them if necessary (Level 2 only).
o Remove redundant soldering flux after repair.
o Meet the torque requirements when assembling the unit (see also the document “torques for
transceiver assembly” on Nokia Partner Web Site).
o Always use your own equipment for testing where you are sure that it works. E.g. if the customer
complains about charger function, please test the phone with your own charger to be sure if phone or
charger causes the malfunction.
o When doing the Faultlogger entries, always note the Item code, which caused the malfunction. Also, fill
in the appropriate part code from the assembly, if needed.
o Please be aware that some malfunctions could be software related and solved by an update.
These mention General Service Bulletins have to be followed:
SB-027: Original Nokia Accessories
SB-089: Don’t try to repair prototypes (indicated on Type Label).
SB-107: Be sure that you have minimum hardware requirements in place.
SB-115: Handling of liquid damages.
SB-121: Return the defective part, if one of your service tools causes malfunction.
SB-124 Service Policy for packaging serviced products
SB-131: Check these guidelines when refurbishing products.
SB-148: Improvements to Faultlog Reporting Tool
SB-156: Packing Material
SB-161: New structure of General Bulletins
SB-163: Service handling of PWBs and PCBs during repair process
SB-164: New barcode for future products
SB-165: NMP Global Symptom Codes
SB-167: NMP Global Fault Codes (Level 1&2)
Standard Tools
SB-011: NMP Standard Toolkit
Spare Parts
SB-004: New swap phone cartons
Please check Nokia Partner Web Site (PWS) for latest news and files on a regular basis.
Service Manual 3100 Level 1&2 Copyright 2003 © Nokia Corporation

Nokia 3100 Specifications

General

FM radio	No
Ringer type	Polyphonic
Interface	Pop-Port, DKU-5
Bundled software	Nokia PC Suite (aviliable separetly)
Operating frequency	EGSM 900, GSM 1800, GSM 1900 MHz
Internal memory	0.484 MB
Product color	White
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Battery type	BL-5C
Battery capacity	850 mAh
Display type	-
Display resolution	128 x 128 pixels
Display number of colors	4096 colors
WAP	1.2.1
Data network	GPRS

Weight and Dimensions

Weight	85 g
